Network design

OFFERINGS



Hexad Solutions Group offers premier network design services, ensuring that our clients receive comprehensive and innovative solutions tailored to their specific needs. By utilizing cutting-edge design tools and methodologies, we empower your team with the most accurate and efficient designs for your fiber network. Our expertise in network design allows you to plan, optimize, and execute your projects with confidence. We are proud to provide:

PLANNING

  • Site Surveys
    • Detailed analysis of proposed cabinet / FDH locations
  • Route / Cable Path Analysis
    • In depth review of propsed cable pathing to enable a smooth permitting and construction phase
  • HLD (High Level Design) Creation
    • Design plan optimization
    • Address validation
    • Distribution area creation

DESIGN

  • Detailed LLD (Low Level Design)
    • Proposed strand, poles, anchors, guys, etc.
    • Fiber cable(s)
    • Proposed vaults & conduits
    • Work area boundary, parcels, service locations, & land base data
    • Splice diagrams
    • BOM / Cost estimates
  • Construction Packages

PERMITTING

  • Permit Creation, Submittal, & Approval
    • Right-Of-Way permit agreements
    • Traffic control plans (TCP’s)
    • Excavation, railroad, DOT, municipality, etc.
    • PE services
    • Submission, tracking, & expediting
  • Joint Use
    • Research & acquisition of local pole attachment agreements
    • Make-ready engineering, pole loading analysis, & clearance analysis as required by the pole owner
    • Creation & submittal of all required information for pole attachment applications
